Poseidon Series
Amprisen
Choose our Charging Cables and enjoy exceptional conversion efficiency, robust load capacity, and outstanding reliability. Join us in advancing towards a smart and efficient future, enhancing your power systems like never before!
Product Features | |
Compliance with Standards | IEC 62196-2 |
Electrical Performance | |
Rated Voltage | 250V/480V |
Rated Current | 16A、32A |
Withstand voltage | 2000V |
Insulation Resistance | >1000MΩ |
Environment Performance | |
Operating Temperature | -30°C~+50°C |
Salt Spray Rating | 500h |
IP Grade | IP54 (with protective cover connected) IP55 (plug and socket connected) |
| Mechanical Properties | |
Mechanical life | >10000times |
Insertion and Extraction Force | ≤100N |
Material Application | |
Enclosure Application | Thermoplastic engineering plastics, complieswith ROHS environmental requirements |
Contact | Copper alloy with silver plating on the surfaceand top thermoplastic plastic. |
Sealing Gasket | Silicone rubber elastomer |
Wire Guage | 16A lphase Wiring:3*2.5mm²+1*0.5mm² 16A 3phase Wiring:5*2.5mm²+1*0.5mm² 32A lphase Wiring:3*6mm²+1*0.5mm² 32A 3phase Wiring:5*6mm²+1*0.5mm² |
