The Type 2 AD Floor Mount EV Charger combines efficient 14/22/44kW charging with a prominent 32" advertising screen. Supporting both single and three-phase power, it features a Type 2 connector, Plug & Play/APP/RFID start, and robust IP65/IK10 protection. Certified to CE/TUV standards, it operates reliably from -10°C to +60°C. A smart solution for commercial locations seeking both charging and advertising capabilities.
| Quantity: | |
|---|---|
Commercial EV Charging Station with Digital Signage
Amprisen
AD Floor Mount EV Charging Station
This innovative Type 2 Floor Mount EV Charging Station combines efficient EV charging with a prominent 32-inch screen for dynamic advertising. It's an ideal solution for high-traffic commercial locations.
| Feature | Specification |
| Input | |
| Power Supply | 1P+N+PE/3P+N+PE |
| Rated Voltage | AC 220V / 380V |
| Rated Current | 16A / 32A |
| Frequency | 50/60Hz |
| Output | |
| Output Voltage | AC 100V - 240V |
| Maximum Current | 32A * 2 |
| Rated Power | 14kW / 22kW / 44kW |
| Charge Connector | Connector with cable / Socket |
| Cable Length | 5m / 0m (socket) |
| User Interface | |
| LED Display | 32" LED screen |
| Start Mode | Plug & Play / APP / RFID |
| Emergency Stop | Yes |
| Ingress Protection | IP65 |
| Impact Protection | IK10 |
| Safety | |
| Electrical Protection | Over current, Residual current, Surge, Ground, Over/Under voltage, Over/Under frequency, Over/Under temperature protection |
| Certification | CE, TUV |
| Certification Standard | EN IEC 61851, EN 62196 |
| Warranty | 1 Year |
| Environment | |
| Work Temperature | -10°C ~ +60°C |
| Work Humidity | 5% ~ 95% |
| Work Altitude | <2000m |
| Panel Specification | |
| Display Size (scale) | 698mm(H) x 392mm(V) |
| Resolving Power | 1920 x 1080 |
| Display Color | 16.7M |
| Contrast Ratio | 3000:1 |
| Viewing Angle | 178°/178° |
| Brightness | 300 cd/㎡ |
| Response Time | 5ms |
| MTBF (Reliability) | 60,000 hours |
| Power Consumption | |
| Power Supply | AC 100V - 240V, 50/60Hz |
| Maximum Power Consumption | ≤160W |
| Standby Power | ≤3W |
| Product Dimension | 550 * 150 * 1600mm |
| Package Dimension | 720 * 300 * 1650mm |
| Gross Weight | 100kg |
| External Package | Wooden box |
This charging station offers a unique combination of efficient EV charging and impactful advertising, making it a smart investment for modern commercial spaces.
