| Charging mode | mode 2 |
|---|---|
| Input/output power rating and current | Single phase up to 3.5kW/16A |
| Input/output voltage | 230V+20%, single phase;50Hz |
| Network type | TT,TN |
| Connector type | IEC 62196 Type2 or Type1 plug, 5m |
| Internal RCD | AC 30mA, DC 6mA |
| Protection | Overcurrent, overvoltage, undervoltage, integrated surge protectionLeakage Protection, Lightning Protection, Waterproof ProtectionOverheat Protection, CP Malfuntion Protection, Short circuit Protection |
|---|---|
| Power measurement accuracy | +/-1.0% from 1% to full scale |
| IP and lK rating | IP65;IK10(Screen:IK08) |
|---|---|
| Operating altitude | 2000m |
| Operating temperature range | -20C~+55C |
| Storage temperature range | -20C~+85C |
| Dimensions(H x W x D) | 210×81.5x55mm |
| Status Indication | LED RGB 20PCS |
|---|---|
| User interface | Easy Charging APP; Easy Charging Cloud |
| Connectivity | Bluetooth,Wi-Fi |
| Communication protocols | MQTT |
| User authentication | APP |
| Interface languages | English/中文/Deutsch/日本語/Italiano/Français/Português/Español |
| Safety and compliance | EN61851-21-2,EN62752,EN17186,EN301489-1,EN301489-17,EN62311, |
|---|---|
| Certification | CE |
| Warranty | 24months,warranty extension possible |
Project fit and buyer notes
Portable EV Charger 01 3 5KW Type2 can be evaluated as part of Amprisen's portable EV charger range. Confirm connector, power, network, certification, branding, and installation requirements before quotation so the final configuration matches the target market and deployment scenario.
| Decision area | What to confirm |
|---|---|
| Market connector | Match Type 1, Type 2, or GBT connector and input plug to the target country before choosing power. |
| Power and phase | Compare 3.5kW, 7kW, 9.6kW, 11.5kW, and 22kW by phase, current, socket type, and grid availability. |
| OCPP and 4G | Use OCPP, 4G, app, and charging records when fleet reimbursement, remote monitoring, or operator control is needed. |
| Safety and records | Confirm MID metering, RCD protection, leakage detection, labeling, and safety documentation when portable chargers are used for fleet, reimbursement, or regulated markets. |
| Variant accuracy | Make sure selected images, thumbnails, datasheet, inquiry model, and specifications match the chosen power and connector. |
Portable EV chargers fit flexible charging, fleet backup, mobile service, rental, and temporary deployment where fixed wallbox installation is slow, expensive, or not available.
Confirm Type 1, Type 2, or GBT connector, input plug, single-phase or three-phase power, current rating, cable length, carrying case, app needs, 4G, OCPP, MID metering, RCD protection, and target certification before quotation.
The main risks are mismatched plug standards, over-specified OCPP for simple private use, unclear safety instructions, cable durability, network coverage for 4G models, and confusing similar shells with different power ratings.
Portable EV Charger 01 3 5KW Type2 can be reviewed for commercial projects when its power, connector, communication, certification, and installation format match the target use case. Share the site and backend requirements before quotation.
OCPP, RFID, app, 4G/WiFi/Ethernet, and remote monitoring requirements should be confirmed by model and project configuration. Amprisen can discuss backend compatibility during the inquiry stage.
Send the target country, connector standard, power level, input phase or grid details, mounting type, communication method, certifications, branding needs, estimated quantity, and expected delivery schedule.
